*Presentation Options
The presentation option at the top of
Figure 12.62
may be used as notation for a model corresponding to the notation at the bottom of the figure. If the action has non-defaulted
metaattribute values, these can be shown with a property list near the variable name.
Figure 12.62 - Presentation option for AddVariableValueAction
